Description

Scope of Delivery:
- 1x GYS TIG welding system with accessories
- TIG welding system, TIG welding torch SR 26 DB 4 m, earth cable 2 m prefabricated, electrode holder 2 m prefabricated

Product Description:
Features and areas of application: Model for pipe fitters, boilermakers and maintenance personnel - Intuitive control panel - 2 different ignition options: Contact ignition with TIG-LIFT and contactless HF ignition - 3 different torch modes: 2-stroke, 4-stroke and 4-stroke LOG - 3 different TIG welding modes: TIG with control of gas pre-flow and post-flow time, current rise time and current intensity, TIG pulse with adjustable frequency and welding current intensity and TIG spot for convenient tacking with deactivated current rise and fall control - AIP function (adjust ideal position) with search arc for finding the welding start position - the device has 10 memory locations in MMA and TIG mode - the MMA pulse mode is ideal for stay welds and also has an adjustable HOT START function - SPOT mode (TIG DC or AC): fast and precise tacking of thin sheets before welding - ignition modes: contactless HF ignition or LIFT ignition by contact for welding in high-frequency sensitive environments - automatic torch recognition: compatible with torches with lamella button and with double button - generator-compatible: +/- 15 % - max. power 7 kW

Technical Data:
- Width: 21cm
- Length: 43cm
- Operating modes: 2-stroke / 4-stroke / 4-stroke LOG
- Ignition type: HF ignition / TIG LIFT
- Weight: 10kg
- Mobility: portable
- Protection class: IP 21
- Type of current: Direct current - DC
- Version: with accessories
- Height: 33cm
- Welding process: TIG, E-hand
- Mains voltage: 230 V / 50/60 Hz
- Fuse protection: 16A
- Pulsing: 0.1 - 900Hz
- Power consumption: 6903W
- Open circuit voltage: 65V
- Welding current range: 5-200 A
- Welding current at 60% duty cycle/40° C: 115 A
- Cooling type: gas-cooled
- Standard: EN 60974-1
- Plug type: F
- Brand: GYSFor commercial use, please observe the building regulations!

For commercial use, please observe the building regulations!

Product form

GYS TIG welding system PROTIG 200 DC HF ( 1000152792 ) with accessories, gas-cooled

SKU: 140318 EAN: 3154020062009
    CHF 923.37
    incl. VAT, plus shipping
